Blue coarse fiber ADL nonwoven fabric for incontinent adult diapers
The main function of ADL (Acquisition Distribution Layer) is to quickly guide and control diffusion, aiming to improve the absorption performance and wearing comfort of the product.
Material :
ES fiberBasic weight :
20-45gsmWidth :
CustomizedColor :
White,green, blue, pink, CustomizedOuter roll diameter :
Max 1100mm, CustomizedProduction process :
Air through bondingType :
HydrophilicPrinting :
CustomizedUsage :
Acquisition distribution layerApplication :
Baby diaper, adult diaper, sanitary napkinPacking details :
In the roll, inside with paper core, wrapping by transparent film and paper board; Strandard export packingPayment terms :
T/T, L/C at sight, DP at sightDelivery time :
7-15 days after receipt of the deposit or L/CMinimum order quantity :
1000.00kgsProduct Description
ADL quick guide layer nonwoven refers to a layer or structure used in a specific technology or application to guide and distribute fluid flow. The main function of the ADL drainage layer in adult diapers is to guide urine to quickly flow towards the absorption layer, ensuring that urine can be absorbed quickly and evenly, thereby avoiding urine accumulation in the diaper and reducing the risk of urine leakage. The design of ADL flow guiding layer can effectively reduce the accumulation of urine in diapers and lower the risk of urinary leakage.Through rapid diversion and uniform distribution, the ADL diversion layer can significantly enhance the absorption efficiency of diapers, ensuring timely absorption and locking of urine within the absorption layer.
Product Attributes
| Items | Unit | Requirement | Result | Test Method | Judging | |
| Basic weight | gsm | 35±2 | 34.6 | Electronic scale | OK | |
| Width | mm | 80±2 | 80 | Thickness gauge (micrometer) | OK | |
| 3D- Dimensional Thickness | mm | 0.65±0.2 | 0.65 | Meter ruler | OK | |
| Tensile strength | MD | N/5cm | ≥56.5 | 59.5 | JIS L1085-2005 | OK |
| CD | ≥12.8 | 13.6 | JIS L1085-2005 | OK | ||
| Breaking elongation | MD | % | ≥36.1 | 38.4 | JIS L1085-2005 | OK |
| CD | ≥67.9 | 69.8 | JIS L1085-2005 | OK | ||
| Fluid Penetrating Rate | 1st | S | ≤2 | 1.11 | OK | |
| 2nd | ≤3 | 2. 37 | OK | |||
| 3rd | ≤4 | 3. 28 | OK | |||
| Softness | / | Soft | Soft | OK | ||
| Fluorescence reaction | / | No | No | OK | ||
| Material was suitable to use in hygiene product. | ||||||
Product Application
ADL quick guide layer nonwoven plays a crucial role in diaper applications, as it not only enhances the absorbency and dryness of diapers, but also improves user experience and comfort. Therefore, the selection and configuration of ADL in adult diaper are crucial in the design and manufacture of diapers.
Factory Workshop
Hygiene materials ADL nonwoven uses the mesh laying machine to evenly lay the combed fiber mesh on the forming mesh, forming a certain thickness of fiber layer. It is combing fibers into a mesh structure, ensuring that the fibers are arranged neatly and evenly distributed.
Lab & Testing
Our factory has a professional R&D technical team, industry-leading production capacity and technology. The raw materials are double-verified to control the quality from the source, reducing the trial and error costs of overseas customers and ensuring stable quality.
Related Products
Our products cover spunbond nonwoven, frontal tape, side tape, fluff pulp, sap, hot melt glue, spandex and other raw materials for baby diaper, sanitary napkin, adult diaper, underpads and pull up diapers. You can contact us for more details.
Warehouse
We have a modern warehouse of over 10,000 square meters, providing customers with “one station” services, which can mix load different kinds of raw materials, which can help our customers to reduce cost.
Packing & Shipment
Renowned for our integrity within the industry, formidable capabilities, and top - notch product quality, we have successfully exported our products to regions including Southeast Asia, Africa, and South America. Backed by a professional and proficient service team and a firm dedication to honesty, we are certain that we can continuously provide value to our customers and establish successful partnerships, thus ensuring a prosperous future.
