Green ADL acquisition distribution layer nonwoven for big waistband diapers
The Acquisition Distribution Layer for diaper, also referred to as diaper ADL non-woven fabric, functions as a crucial middle layer in diapers, situated between the topsheet and the absorbent core. Unlike the thin and delicate topsheet, the ADL boasts a prominent diversion pattern design that is clearly discernible on the diaper's exterior surface.
Material :
ES fiberBasic weight :
20-45gsmWidth :
CustomizedColor :
White,green, blue, pink, CustomizedOuter roll diameter :
Max 1100mm, CustomizedProduction process :
Air through bondingType :
HydrophilicPrinting :
CustomizedUsage :
Acquisition distribution layerApplication :
Baby diaper, adult diaper, sanitary napkinPacking details :
In the roll, inside with paper core, wrapping by transparent film and paper board; Strandard export packingPayment terms :
T/T, L/C at sight, DP at sightDelivery time :
7-15 days after receipt of the deposit or L/CMinimum order quantity :
1000.00kgsProduct Description
ADL diaper acquisition distruibution layer plays an indispensable role in diapers. As a key component of diapers, it is located between the surface layer and the absorbent core. Through its unique fiber structure and flow guiding design, it can quickly conduct urine from the surface layer to the absorbent core and help the liquid to be evenly distributed in the core. This feature not only improves the absorption speed of diapers, but also reduces the time urine stays on the surface layer, effectively reducing the possibility of re infiltration. The use of diaper ADL quick guide layer fabric also helps to keep the baby's skin dry and prevent skin problems such as diaper rash. Therefore, ADL flow guiding non-woven fabric is an indispensable and important material in the manufacturing of diapers.
Product Attributes
| Items | Unit | Requirement | Result | Test Method | Judging | |
| Basic weight | gsm | 35±2 | 34.6 | Electronic scale | OK | |
| Width | mm | 80±2 | 80 | Thickness gauge (micrometer) | OK | |
| 3D- Dimensional Thickness | mm | 0.65±0.2 | 0.65 | Meter ruler | OK | |
| Tensile strength | MD | N/5cm | ≥56.5 | 59.5 | JIS L1085-2005 | OK |
| CD | ≥12.8 | 13.6 | JIS L1085-2005 | OK | ||
| Breaking elongation | MD | % | ≥36.1 | 38.4 | JIS L1085-2005 | OK |
| CD | ≥67.9 | 69.8 | JIS L1085-2005 | OK | ||
| Fluid Penetrating Rate | 1st | S | ≤2 | 1.11 | OK | |
| 2nd | ≤3 | 2. 37 | OK | |||
| 3rd | ≤4 | 3. 28 | OK | |||
| Softness | / | Soft | Soft | OK | ||
| Fluorescence reaction | / | No | No | OK | ||
| Material was suitable to use in hygiene product. | ||||||
Product Application
The diaper ADL nonwoven fabric is a crucial raw material in diaper manufacturing, suitable for baby diapers, adult incontinence products, disposable nursing pads, and sanitary napkins.
Factory Workshop
ADL nonwoven fabric is combing fibers into a mesh structure, ensuring that the fibers are arranged neatly and evenly distributed. By using the mesh laying machine to evenly lay the combed fiber mesh on the forming mesh, forming a certain thickness of fiber layer.
Lab & Testing
Our factory has a professional R&D technical team, industry-leading production capacity and technology. The raw materials are double-verified to control the quality from the source, reducing the trial and error costs of overseas customers and ensuring stable quality.
Related Products
Our products cover spunbond nonwoven, frontal tape, side tape, fluff pulp, sap, hot melt glue, spandex and other raw materials for baby diaper, sanitary napkin, adult diaper, underpads and pull up diapers. You can contact us for more details.
Warehouse
We have a modern warehouse of over 10,000 square meters, providing customers with “one station” services, which can mix load different kinds of raw materials, which can help our customers to reduce cost.
Packing & Shipment
Renowned for our integrity within the industry, formidable capabilities, and top - notch product quality, we have successfully exported our products to regions including Southeast Asia, Africa, and South America. Backed by a professional and proficient service team and a firm dedication to honesty, we are certain that we can continuously provide value to our customers and establish successful partnerships, thus ensuring a prosperous future.
